Product Description:
- Long range 24-hours monitoring.
- Delicate and smooth images．
- Convenient for installation and application.
- 360 degree of Omni-directional Pan-Tilt
- Super-strong aluminum alloy with IP67
- Higher sensitivity
- Effective in all environments
- Lightweight design: weight ≤ 10kg
In terms of durability and reliability, the PTZ Thermal Imaging Camera is designed to withstand extreme temperature conditions. With a storage temperature range of -30°C to +70°C, this camera is well-suited for outdoor use in harsh environments, ensuring consistent performance even in challenging weather conditions.
Overall, the PTZ Thermal Imaging Camera is a versatile and powerful thermal security camera that offers advanced features and capabilities at a competitive thermal camera price. Whether used for surveillance, monitoring, or detection purposes, this camera is a valuable tool for enhancing security and safety in various settings.
Features:
- Support image scale, support LRF, support access to multiple sensors.
- Highly intelligent: support hotspots, smoke and fire alarms, temperature detection; support area intrusion detection; support vehicle, boat and human detection, classification and identification; support target tracking, screening and filtering; support AR intelligent information fusion linkage.
- Active defence: support for loud speaker + flashing lights to deter or deny criminals.
- Pitch: -90°to +90°, horizontal 360°continuous rotation, full coverage of 720° three-dimensional
Technical Parameters:
| Model |
HP-DMS10-2132 |
| Distance |
Day: 2000m
Night: 1000m
|
| Visible Camera |
1. Sensor type: back-illuminated ultra-low illumination starlight CMOS
2. Minimum illumination: color: 0.0005Lux @ black and white: 0.0001Lux @ 0Lux(IRON)
3. Lens:7mm～330mm, 47 times optical zoom, 16 times digital zoom.
4. Image processing: white balance, electronic shutter, frame accumulation, backlight compensation, glare suppression, 2D/3D digital noise reduction, electronic anti-shake, wide dynamic.
5. Day and night light: 0.4-0.75um visible light wide spectral window and 0.8-0.95um near-infrared spectral window day and night independent double light window, improve the signal-to-noise ratio of imaging light and stray light
6. Support electronic fog penetration and optical fog penetration
|
|
Laser
illuminator
|
1. Laser Homogenization: new infrared GHT-III HD flood light source, no scattered particles.
2. Laser angle: 2.1°～20°, DSS digital stepping lighting angle control technology, 0.1° precise follow-me control, automatic tracking or manual fine-tuning intelligent matching.
3. Laser distance: 1000m
4. Control modes: forced on, forced off, light sensitive automatic control in three modes, all can be set remotely
|
| Video audio |
1. Thermal camera resolution:support 1920×1080；1280×1024；1280×960；1024×768；1280×720；704×576；640×512；640×480；400×300；384×288；352×288；352×240
2. Visible camera resolution:2592×1520；2560×1440；1920×1080；1280×1024；1280×960；1024×768；1280×720；704×576；640×512；640×480；400×300；384×288；352×288；352×240
3. Video encoding: H.265/H.264/MJPEG,multi-stream support
4. Video code rate:32Kbps～16Mbps
5. Audio encoding:G.711A/ G.711U/G726
6. Image flip: left and right / up and down / diagonal
7. OSD settings: Support OSD display settings for channel name, time, gimbal orientation, field of view, focal length, and preset bit name settings
|
| Intelligent functions |
1. Intelligent analysis: support intrusion detection, boundary crossing detection, entering/leaving area detection, motion detection, wandering detection, people gathering, fast moving, target tracking, items left behind, items taken; people/vehicle target detection, face detection; and support 16 area settings; support intrusion detection people, vehicles filtering filtering function.
2. Automatic tracking: support single scene tracking/support multi-scene tracking/support panoramic tracking/support alarm linkage tracking.
3. Intelligent information fusion: support 512 AR intelligent information fusion, intelligent analysis of video identification information fusion, support orientation angle, field of view angle, focal length, magnification information fusion
4. Alarm management: support alarm capture and upload
|
| Enhanced Features |
1. Distance measurement: support passive distance measurement; support optional laser distance measurement.
2. Support sound and light alarm: internal integrated tweeter + flashing light, support alarm sound customization.
3. Support alarm linkage fire fighting device.
4. Camera diagnostic functions: support disconnection alarm, support IP conflict alarm, support illegal access alarm (illegal access times, lock time can be set), support SD card abnormal alarm (SD space is insufficient, SD card error, no SD card), video masking alarm, anti-sun damage (support threshold, masking time can be set).
5. Whole life management: health index record function, support working time, shutter count, working temperature, limit temperature, etc.; zoom lens and head each motor working cumulative time, etc.
6. Support disconnection renewal.
7. Power failure memory: support can restore the position before power failure, preset point state, cruise state, line sweep state.
8. Remote maintenance: with fault query, self-test, remote restart function; online upgrade, remote upgrade.
9. Key frame setting: support key frame interval 100 levels adjustable.
10. Configuration file: support configuration file import and export function.
11. Web access: support WEB full function configuration, remote online upgrade.
|
| Safety control |
1. Support illegal access alarm: the number of illegal access, lock time can be set.
- Support three levels of user rights management, administrator, operator and normal user.
- Security mode: authorized user name and password, support IP whitelist and blacklist, MAC whitelist and blacklist.
- User mis-login lockout
|
| PT |
1. Rotation speed: Horizontal: 0.01°/s～100°/s; Pitch: 0.01°/s～80°/s, support focal speed adaption.
2. Rotation angle: horizontal: 360° continuous rotation; pitch: -90°～+90°
3. Structure material: quasi-spherical design of micro-rotary, integrated 5-window multi-channel, fine cast high strength aluminium alloy material.
4. Window glass: infrared/visible high efficiency optical glass, clean film coating.
5. Surface coating: PTA triple anti-corrosion coating, anti-corrosion.
6. Wiper: support intelligent automatic wiper
7. Defrost: visible window defrost
8. Preset position cruise: 3000 preset positions, support 16 cruise routes, each can support 256 preset positions
9. Watch function: preset bit / pattern scan / cruise scan / vertical scan / frame scan / panorama scan / apple skin scan / horizontal fan sweep line scan
10. Support 3D frame selection zoom
11. Orientation information: support angle query/real-time return and positioning; support lens field of view return and positioning
12. Zero point correction: support northward zero point remote correction function
|
| Electrical interface |
1. Communication and control: 1 *RJ45 Ethernet port; 2* alarm inputs, 1 *alarm output; 1 *audio input input, 1 *RS485 interface.
2. Protocol: Support HTTP, HTTPS, FTP, SMTP, DNS, NTP, RTSP, RTCP, RTP, TCP, UDP, ICMP, DHCP network protocols; support ONVIF and GB28181 protocols.
3. Development interface: Support HP-SDK secondary development
|
| Power supply |
1. Working voltage: DC 9~36V, external AC220V or battery power adapter.
- Peak power consumption: ≤60W
|
| Environmental adaptation |
1. Working temperature: -40℃～60℃
- Working humidity: ≤95%
- Protection grade: IP67
- Anti-salt spray: no change in surface after 96 hours of continuous spraying at pH 6.5~7.2
- Electromagnetic compatibility: anti-surge 6KV, anti-static 8KV contact / 15KV air
|
| Volume weight |
1. Weight: ≤10kg
- Size: 312mm×200mm×296mm (L×W×H)
- Mounting: Front / side / wall / hanging / vehicle / tripod pro-rack
|
Company:
Hope Wish Photoelectronics Technology Co., Ltd. was established in Jinan high tech Zone and has a core R&D team for laser imaging, infrared thermal imaging detection and tracking technology research and product. Hope-Wish focuses on the research and development of night vision and multispectral imaging technology, by using a variety of image analysis and processing technology based on artificial intelligence to provide users with comprehensive optoelectronic system solutions in long-distance, high-definition, intelligent, multi-purpose, all-weather and complex environments.
Hope-Wish solutions cover the border/coastal defense, anti UAV, intelligent transportation, forest fire prevention, environmental protection, individual photoelectric equipment (handheld, helmet, gun aiming), marine and other industries. The products developed by the Hope-Wish, with their excellent performance, reliable quality and thoughtful after-sales service has been widely praised by users all over the world.Applications:
The Hope-Wish HP-DMS PTZ Thermal Imaging Camera is a versatile and advanced surveillance tool suitable for a wide range of applications and scenarios. With its cutting-edge technology and robust design, this thermal PTZ camera is ideal for various industries and environments.
One of the key product attributes of the Hope-Wish HP-DMS is its thermal imaging capability, which allows it to detect and capture images in complete darkness or challenging lighting conditions. This makes it perfect for night surveillance, border security, and monitoring remote locations where traditional cameras may struggle to provide clear images.
Another standout feature of the HP-DMS is its PTZ functionality, which enables it to pan 360 degrees continuously and tilt up to 90 degrees. This wide range of motion allows the camera to cover large areas and track moving objects with precision, making it suitable for monitoring expansive outdoor spaces, such as parking lots, construction sites, and industrial facilities.
Equipped with advanced image processing technology like Digital Detail Enhancement, the HP-DMS delivers high-quality thermal images with enhanced clarity and detail. This makes it a valuable tool for applications that require accurate identification and analysis of objects or individuals, such as perimeter security, search and rescue operations, and wildlife monitoring.
The HP-DMS also features built-in alarm functions, including motion detection and temperature alarm, which can alert users to potential threats or abnormal conditions in real-time. These alarm capabilities enhance the camera's effectiveness in security applications, such as intrusion detection, fire prevention, and asset protection.
Designed to withstand challenging environmental conditions, the Hope-Wish HP-DMS PTZ Thermal Imaging Camera is built in China and can operate in high humidity environments up to 95% RH. This durability makes it suitable for outdoor installations in regions with variable weather conditions, such as coastal areas, jungles, and deserts.
Support and Services:
The PTZ Thermal Imaging Camera product comes with comprehensive Product Technical Support and Services to ensure optimal performance and user satisfaction. Our dedicated technical support team is available to assist with any inquiries, troubleshooting, or setup assistance. Our services also include periodic maintenance, firmware updates, and technical consultations to address any specific requirements or challenges. Rest assured that our team is committed to providing reliable and efficient support to maximize the functionality and longevity of your PTZ Thermal Imaging Camera.
Packing and Shipping:
Product Name: PTZ Thermal Imaging Camera
Description: The PTZ Thermal Imaging Camera is a high-quality camera designed for capturing thermal images with precision and accuracy.
Features:
- High-resolution thermal imaging
- 360-degree pan, tilt, and zoom functionality
- Advanced thermal detection technology
- Weatherproof and durable construction
Shipping Information:
We offer fast and reliable shipping for the PTZ Thermal Imaging Camera. All orders are processed within 1-2 business days and shipped via expedited shipping for quick delivery.
For international orders, additional shipping charges may apply. Please contact us for more information.
FAQ:
Q: What is the brand of this PTZ Thermal Imaging Camera?
A: The brand of this PTZ Thermal Imaging Camera is Hope-Wish.
Q: What is the model number of this PTZ Thermal Imaging Camera?
A: The model number of this PTZ Thermal Imaging Camera is HP-DMS.
Q: Where is this PTZ Thermal Imaging Camera manufactured?
A: This PTZ Thermal Imaging Camera is manufactured in China.
Q: What are the key features of the HP-DMS PTZ Thermal Imaging Camera?
A: The key features of the HP-DMS PTZ Thermal Imaging Camera include pan-tilt-zoom functionality, thermal imaging capabilities, high resolution, and advanced imaging technology.
Q: Is the HP-DMS PTZ Thermal Imaging Camera suitable for outdoor use?
A: Yes, the HP-DMS PTZ Thermal Imaging Camera is designed for outdoor use and is equipped to withstand various weather conditions.
